DKT50

BlueLite is a secure card reader designed by Datecs. It communicates with smart phones trough a BLE interface and accepts chip cards, mag-stripe cards and contactless cards. The reader is designed to support Pin on Mobile technology and comes with the famous Datecs SDK for iOS, Android and Windows.



CPU

Secure ARM Cortex M4

Buttons

On/Off button

Smart Card Reader

Friction type

Contactless Reader

NFC-A, ISO 14443 Type A

NFC-B, ISO 14443 Type B

NFC-F, Felica

NFC-V, ISO 15693

Contactless Payments

VISA payWave

MasterCard Contactless

American Express ExpressPay

Discover D-Pas

Connectors

USB Type-C port

Wired Communication

USB (device)

RS-232

OS Compatibility

Windows

LED Indication

Contactless payment status

Audio Features

Electromagnetic buzzer

Power Supply

DC 5 V through USB

Battery

Rechargeable Li-Po Battery 3.7 V, 500 mAh

Reliability

1,000,000 magnetic card swipes 500,000 chip card cycles

Certificates

CE

PCI 6.x

EMV Level 1 Contactless

TQM

IP65

IK08

Dimension W x D x H

105 x 22 x 73 mm

Weight

95 g

Operational Temperature

-10 °C to 40 °C / 5 to 90% RH

Storage Temperature

-15 °C to 50 °C / 5 to 90% RH

Other Box Contents

DKT-50

90 cm USB Type-A to USB Type-C cable
